Designed & Manufactured in Canada eh!

Genesis

7,000 Lux Output / Smart / Intrinsically Safe / Cordless
Share on Social

Highlights

  • Light output: 7,000 Lux
  • Run time: Main LED: 14 hrs minimum, Low-Light/Emergency LED: 7 days minimum
  • Tracking-tag or proximity tag-enabled
  • Intrinsically safe certified to IECEx, ATEX and MSHA standards
  • MSHA-certified with Extronics / AeroScout tracking tag
  • Customizable for bidirectional communication
  • IP67
  • Serviceable battery and components
  • 2-year warranty
  • Flexible hardhat mounting options – fixed and adjustable clips
  • Multiple charger configuration options (single, 4-unit, 10-unit, 24-unit and 48-unit)
  • Anti-theft locking device
  • Vehicle charger

Smart Features

Tracking-tag (Wi-Fi, RFID, Bluetooth or LTE) or proximity-tag enabled
Tags are primarily used for location tracking of personnel and access control. A key benefit is pinpointing the location of miners during an emergency. Proximity tags are used for worker safety.

Tag is powered by the lamp
Once installed into the NLT lamp, there is never a need to change the tag battery. The Genesis lamp provides optimum power for the tag.

Bidirectional communication
Limited bidirectional capability is enabled through the push button on the headpiece. This button is used for a variety of functions, including (but not limited to) emergency assistance (man-down) requests, acknowledging a signal/warning or triggering a warning/alarm.

Programmable cap lamp lights
The fully programmable cap lamp light can be used for a variety of notifications, including safety or operational alerts, e.g., for a man-down or evacuation signal, it can flash in a pre-programmed sequence. It can also be used to signal shift change or report-to-surface instructions.

Integrated
By having the tag integrated into the cap lamp, the tag will not get left behind. Having the tag always on the miner is a very important safety consideration.

More About Genesis

NLT’s line of Smart Lamps debuted with Genesis, the world’s first cordless cap lamp to accommodate a tracking tag. For use in the harshest environments, the intrinsically safe (IS), all-in-one Genesis cap lamp has the capacity to accommodate a variety of tracking tag options while keeping the battery and light source in a single high-impact, IP67 enclosure. Its innovative engineering makes it programmable, with custom functionality to support 3rd-party solutions, as well as customizable for bidirectional communication.

Genesis is certified IS to ATEX, IECEx and MSHA as a tag-ready, standalone lamp and certified MSHA IS with Extronics / AeroScout Wi-Fi tracking tags. This cap lamp is an ideal choice for mines looking for a cordless lamp today with plans to introduce tracking in the future. Since the launch of the Genesis cap lamp, NLT has worked with tracking and proximity providers around the world to fit their tags into our all-in-one design.

The battery and all components of the Genesis are serviceable, increasing the life of the lamp, lowering the total cost of ownership and ultimately reducing waste. Check with your authorized NLT distributor or NLT for service or training.

Specifications

Battery Charge Time:

< 10 hours

Run Time:

Main LED > 14 hours
Low-Light/Emergency LED > 7 days

Weight:

188g (6.6oz)
Light Output:  7,000 Lux

Charger Configuration:

Single, 4, 10, 24 and 48-unit rack; 12 VDC model for vehicle connection

Charger Power Source:

120V or 240V models

Charging Temperature:

5°C to 35°C (optimum 15°C to 20°C)

Water and Dust Protection:

IP67

Approvals:
(depending on version)

Intrinsically Safe approved by ATEX, IECEx, MSHA.

Resources

Data Sheet – English

Data Sheet – Spanish

Data Sheet – French

Smart Cap Lamps Comparison Chart – English

Smart Cap Lamps Flyer – English

Smart Cap Lamps Comparison Chart – Spanish

Smart Cap Lamps Flyer – Spanish

Smart Cap Lamps Comparison Chart – French

Smart Cap Lamps Flyer – French

Component Field Replacement Information

The battery and all components of each NLT cap lamp are serviceable, increasing the life of the lamp, lowering the total cost of ownership and ultimately reducing waste. Check with your authorized NLT distributor or NLT for service or training.

Accessories

Locking Device

Locking Device

NL8058

  • This locking device is designed for use with all-in-one-cap lamps

Adjustable Locking Clip

Adjustable Locking Clip

NL0329

  • Adjustable clip with a security locking feature to prevent cap lamp from falling out of the hard hat bracket

Adjustable Magnetic Clip

Adjustable Magnetic Clip

NL0314

  • An adjustable clip with a magnet so the lamp can be attached to any metallic surface
  • Attaches easily to most hard hats

Mini Adjustable Magnetic Clip

Mini Adjustable Magnetic Clip

NL0312

  • An adjustable clip with a magnet so the lamp can be attached to any metallic surface

Fixed Mounting Clip

Fixed Mounting Clip

NL8005

  • Cap lamp is designed so that the angle of the light shines in the normal working areas at all times and there is no need to pivot the lamp

NLT Breakaway Lanyard

NLT Breakaway Lanyard

NL8602

  • Adjustable and detachable lamp lanyard with an aluminum swivel hook
  • Cap lamps can be worn comfortably around the neck

NLT Lanyard

NLT Lanyard

NL8606

  • 3.8′ (.95 cm) flat breakaway lanyard with swivel hook
  • Cap lamps can be worn comfortably around the neck

Dust Protector

Dust Protector

NL7807-P10

  • Keep dust and debris off your lenses with these tear-away protectors
  • Pack of 10

Nano Lens Protector

Nano Glass Lens Protector

NL7901-P10

  • Made from the same material that protects your phone screen
  • Its 9H hardness resists scratching, which can attract dust
  • Easily applied and removed

Warranty

Northern Light Technologies (NLT) guarantees that Eclipse*, Polaris, Polaris Plus, Genesis*, Genesis Plus*, Rebel and Rebel Plus cap lamps, and related charging systems, will be free of material and workmanship defects for a period of 24 months from the serialized date on the product.

Messenger, Eagle*, Eagle Plus*, Falcon* and Falcon Plus* cap lamps, and related charging systems, and the NLT Automated Cap Lamp Output Tester will be free from defects in material and workmanship for a period of 12 months from the serialized date on the product.

Excluded from the warranty are items or components that are considered to be prone to high wear, such as: rubber components, cables, strain reliefs, covers, lenses and clips.

This warranty does not apply to NLT product performance due to the installation or integration of non-approved third-party components or solutions, such as, but not limited to tracking tags.

This warranty is conditional upon the proper use, maintenance, operation, charging and protection according to instructions within NLT User Guides.

NLT’s responsibility for any loss or damages, regardless of cause, shall not exceed, under any circumstances, the original purchase price of the product to the original purchaser.

*Tag warranty is based on that offered by the 3rd-party solution provider.

Non-Warranty Repairs Policy
NLT will repair any product that is outside the Warranty Policy under the following conditions:

  • All returns must be approved by an NLT customer service representative in advance through the issuance of a Return Goods Authorization (RGA) number. Equipment returned without an RGA number will be subject to an administration surcharge of $50.00,
  • Equipment returned to NLT with no fault found will be subject to a minimum troubleshooting charge of $10.00 per piece of equipment, plus shipping and handling,
  • Refused estimates or units that are uneconomical to repair are subject to a minimum troubleshooting charge of $10.00 per unit,
  • Troubleshooting charges may be applied as a discount to replacement purchases if made within 30 days,
  • Repaired or replaced components are further warranted for 1 year from the repair date excluding high-wear components as detailed above.

10-Mar-2022
