Designed & Manufactured in Canada eh!Rebel Plus
10,000 – 15,000 Lux Light Output / Dual-Beam Technology / Industrial / Recreational / Cordless
Highlights
- Dual-Beam technology
- Light output: 10,000 Lux (15,000 Lux in Dynamic Turbo Bright mode)
- Run time: Main LED: 13 hours minimum in standard mode; up to 6 hours if Dynamic Turbo Bright mode is exclusively used; Low-Light/Emergency LED: 7 days minimum
- Lightweight and compact
- IP67
- Serviceable battery and components
- 2-year warranty
- Flexible hardhat mounting options – fixed and adjustable clips
- Multiple charger configuration options (single, 4-unit, 10-unit, 24-unit and 48-unit)
- Anti-theft locking device
Dual-Beam Features
The Rebel Plus features three beam pattern options plus a Low-Light/Emergency Setting:
- Focused Spot – NLT’s traditional beam pattern
- Wide-Angle Flood Light – a flat, even light; ideal for close-up work
- Dual-Beam – combines both beam patterns to provide a center spot with great peripheral lighting
- Low-Light/Emergency Setting – reduces light output when needed
Dynamic Turbo Bright
- A new feature that increases light output in any of the three beam patterns by 50%. Dynamic Turbo Bright mode will remain engaged for up to six hours unless disengaged.
More About the Rebel Plus
The Rebel Plus is NLT’s rugged, cordless cap lamp designed for outdoor and industrial applications. Now featuring Dual-Beam technology, the cap lamp provides three beam patterns and Dynamic Turbo Bright, an added feature that increases any of the beams by 50% for up to six hours. It also provides a low-light setting for extended or emergency use.
The Rebel Plus is an ideal choice for surface mining, construction, industrial, hunting or recreational (including skiing and cycling) use.
The battery and all components of the Rebel are serviceable, increasing the life of the lamp, lowering the total cost of ownership and ultimately reducing waste. Check with your authorized NLT distributor or NLT for service or training.
Specifications
|
Battery Charge Time: |
< 10 hours |
|
Run Time: |
Main LED > 13 hours Dynamic Turbo Bright mode only – up to 6 hours Low-Light/Emergency LED > 7 days minimum |
|
Weight: |
170g (6oz) |
| Light Output: | 10,000 Lux / 15,000 Lux with Dynamic Turbo Bright |
|
Charger Configuration: |
Single, 4, 10, 24 and 48-unit; 12 VDC adapter for vehicle connection |
|
Charger Power Source: |
120V or 240V models |
|
Charging Temperature: |
5°C to 35°C (optimum 15°C to 20°C) |
|
Water and Dust Protection: |
IP67 |
Resources
Data Sheet – English
Data Sheet – Spanish
Data Sheet – French
Rebel/Rebel Plus Comparison Chart
Why Switch to Plus Flyer
The battery and all components of each NLT cap lamp are serviceable, increasing the life of the lamp, lowering the total cost of ownership and ultimately reducing waste. Check with your authorized NLT distributor or NLT for service or training.
Adjustable Clip
NL0337
- Newer clip designed to accommodate a wide range of hard hats
- Specifically engineered for hard hats with a wide plastic pocket where the lamp mounts, such as the Petzl ST hard hat
Locking Device
NL8058
- This locking device is designed for use with all-in-one-cap lamps
Adjustable Locking Clip
NL0329
- Adjustable clip with a security locking feature to prevent cap lamp from falling out of the hard hat bracket
Mini Adjustable Magnetic Clip
NL0312
- An adjustable clip with a magnet so the lamp can be attached to any metallic surface
Adjustable Clip Small
NL0328
- Adjustable clip with a security locking feature to prevent cap lamp from falling out of the hard hat bracket
Adjustable Magnetic Clip
NL0314
- An adjustable clip with a magnet so the lamp can be attached to any metallic surface
- Attaches easily to most hard hats
Standard Adjustable Clip
NL0302
- Allows the user to adjust the angle of the light beam
- Attaches easily to most hard hats
Fixed Mounting Clip
NL8005
- Cap lamp is designed so that the angle of the light shines in the normal working areas at all times and there is no need to pivot the lamp
NLT Breakaway Lanyard
NL8606
- Adjustable and detachable lamp lanyard with an aluminum swivel hook
- Cap lamps can be worn comfortably around the neck
NLT Lanyard
NL8602
- 3.8′ (.95 cm) flat breakaway lanyard with swivel hook
- Cap lamps can be worn comfortably around the neck
Nano Glass Lens Protector
NL7901-P10
- Made from the same material that protects your phone screen
- Its 9H hardness resists scratching
- Easily applied and removed
Lamp Pouch
NL8601
- Protect your investment with this pouch designed for all-in-one cap lamps
- Black with NLT logo
Warranty
SEPT 6, 2024
Northern Light Technologies (NLT) guarantees that Eclipse, Polaris and Rebel cap lamps (including Plus versions), and related charging systems, will be free of material and workmanship defects for a period of 24 months from the serialized date on the product.
Genesis, Eagle and Falcon (including plus versions) and Aries cap lamps and related charging systems and the NLT Automated Cap Lamp Output Tester will be free from defects in material and workmanship for a period of 12 months from the serialized date on the product.
For lamps with third-party electronics installed, such as tags, the warranty is based on the third-party product and excluded from this policy.
Excluded from the warranty are items or components that are prone to high wear such as: rubber components, cables, strain reliefs, covers, lenses and clips.
This warranty does not apply to NLT product performance due to the installation or integration of non-approved third-party components or solutions, such as, but not limited to tracking tags.
This warranty is conditional upon the proper use, maintenance, operation, charging, and protection according to instructions within NLT User Guides.
Northern Light Technologies’ responsibility for any loss or damages, regardless of cause, shall not exceed, under any circumstances, the original purchase price of the product to the original purchaser.
Shipping of warranty products to NLT is the responsibility of the distributor / customer. NLT will ship repaired or replaced products back at no charge.
NON-WARRANTY REPAIRS POLICY
Northern Light Technologies will repair any product that is outside the Warranty Policy under the following conditions:
- All returns must be approved by an NLT customer service representative in advance through the issuance of a Return Goods Authorization (RGA) number. Equipment returned without an RGA number will be subject to an administration surcharge of $50.00,
- Equipment returned to NLT with no fault found will be subject to a minimum troubleshooting charge of $10.00 per piece of equipment, plus shipping and handling,
Refused estimates or units that are uneconomical to repair are subject to a minimum troubleshooting charge of $10.00 per unit, - Troubleshooting charges may be applied as a discount to replacement purchases if made within 30 days,
- Shipping in both directions for non-warranty products is the responsibility of the customer,
- Repaired or replaced components are further warranted for 1 year from the repair date excluding high wear components as detailed above.
